INTRODUCTION
Vibrating feeder is heavy-duty machine for primary crushing stage feeding in quarry and mining industry.
ADVANTAGES
Super heavy trough structure
Strong vibration intensity, large operation capacity Rotating shaft motor shock absorber
Various grizzly bar sections for high efficiency pre-sieving Modularization design
PARAMETER
| Model | Max Feed Size (mm) |
Capacity (t/h) |
Power (kw) |
Installation Angle (°) |
Size of Funnel (mm) |
| ZSW-280×85 | 450 | 100-160 | 7.5 | 3-5 | 2800×850 |
| ZSW-380×95 | 500 | 160-230 | 11 | 3-5 | 3800×950 |
| ZSW-490×110 | 580 | 200-300 | 15 | 3-5 | 4900×1100 |
| ZSW-590×110 | 600 | 200-300 | 22 | 3-5 | 5900×1100 |
| ZSW-490×130 | 750 | 400-560 | 22 | 3-5 | 4900×1300 |
| ZSW-600×130 | 750 | 400-560 | 22 | 3-5 | 6000×1300 |
| ZSW-600×150 | 1000 | 500-900 | 30 | 3-5 | 6000×1500 |
| ZSW-600×180 | 1200 | 700-1200 | 37 | 3-5 | 6000×1800 |
| ZSW-600×200 | 1400 | 900-1800 | 45 | 3-5 | 6000×2000 |
| ZSW-600×240 | 1400 | 1500-2000 | 75 | 3-5 | 6000×2400 |
| GZD-650×2300 | 300 | 80-100 | 2×1.1 | 10-20 | 650×2300 |
| GZD-750×2500 | 350 | 100-130 | 2×1.1 | 10-20 | 750×2500 |
| GZD-850×3000 | 400 | 120-150 | 2×3 | 10-20 | 850×3000 |
| GZD-1000×3600 | 500 | 150-200 | 2×3.7 | 10-20 | 1000×3600 |
| GZD-1100×3600 | 580 | 240-300 | 2×3.7 | 10-20 | 1100×3600 |
| GZD-1300×3600 | 650 | 450-600 | 2×5.5 | 10-20 | 1300×3600 |
| GZD-1500×3600 | 1050 | 450-1000 | 2×7.5 | 10-20 | 1500×3600 |
