On the whole, screens have adopted an innovative modular design and a finite element dynamic analysis framework, thus improving the fatigue resistance and reliability of the equipment; in addition, the high vibration intensity and SV vibrator can fully guarantee the high yield, high efficiency and low costs during operating.
ADVANTAGES
Reliable, efficient and convenient SV vibrator Flexible drive
High tensioned bolts for heavy duty working condition Wear-resistant and impact-resistant rubber liners
PARAMETER
| Model | Number of Screening Layers | Screening Surface Inclination (°) | Screening Area (m²) | Vibration Frequency (r/min) |
Double Amplitude (mm) | Capacity (t/h) |
Power (kw) |
Overall Dimensions (L×W×H) (mm) |
| YK1235 | 1 | 15 | 4.2 | 970 | 6-8 | 20-180 | 5.5 | 3790×1847×1010 |
| 2YK1235 | 2 | 15 | 4.2 | 970 | 6-8 | 20-180 | 5.5 | 4299×1868×1290 |
| 3YK1235 | 3 | 15 | 4.2 | 970 | 6-8 | 20-180 | 7.5 | 4393×1868×1640 |
| YK1545 | 1 | 17.5 | 6.75 | 970 | 6-8 | 25-240 | 11 | 5030×2200×1278 |
| 2YK1545 | 2 | 17.5 | 6.75 | 970 | 6-8 | 25-240 | 15 | 5767×2270×1550 |
| 3YK1545 | 3 | 17.5 | 6.75 | 970 | 6-8 | 25-240 | 15 | 5874×2270×1885 |
| YK1548 | 1 | 17.5 | 7.2 | 970 | 6-8 | 28-270 | 11 | 5330×2228×1278 |
| 2YK1548 | 2 | 17.5 | 7.2 | 970 | 6-8 | 28-270 | 15 | 6067×2270×1557 |
| 3YK1548 | 3 | 17.5 | 7.2 | 970 | 6-8 | 28-270 | 15 | 5147×2270×1885 |
| YK1860 | 1 | 20 | 10.8 | 970 | 6-8 | 52-567 | 15 | 6536×2560×1478 |
| 2YK1860 | 2 | 20 | 10.8 | 970 | 6-8 | 32-350 | 18.5 | 6826×2570×1510 |
| 3YK1860 | 3 | 20 | 10.8 | 970 | 6-8 | 32-350 | 18.5 | 7145×2570×1910 |
| YK2160 | 1 | 20 | 12.6 | 970 | 6-8 | 40-720 | 18.5 | 6535×2860×1468 |
| 2YK2160 | 2 | 20 | 12.6 | 970 | 6-8 | 40-720 | 22 | 6700×2870×1560 |
| 3YK2160 | 3 | 20 | 12.6 | 840 | 6-8 | 40-720 | 30 | 7146×2960×1960 |
| YK2460 | 1 | 20 | 14.4 | 970 | 6-8 | 50-750 | 18.5 | 6535×3210×1468 |
| 2YK2460 | 2 | 20 | 14.4 | 840 | 6-8 | 50-750 | 30 | 7058×3310×1760 |
