Structural features: it is capable of self-absorbing air and pulp, and its cas er-style, two sided blades are equipped on the impeller capable of the double circulation for pulp inside the slot; its clearance with cover plate is big which will exert small impact on the suction when abrading; its suction intensity is big with forward-lean slot body and little dead angle, making the foam move fast .
Performance and features : big suction intensity and low energy consumption; it doesn’t need foam pump for its vertical layout; the peripheral speed of the impeller is low; the cover plate is durable; the pulp is capable of the conducting downward and upward circulation in the fixed way that will be good for the suspension of the coarse mineral.
The united flotation machined can be formed after combining with JJF-type flotation machine which acts as the suction slot for every single operation.
PARAMETER
| Model | Effective Volume (m³) | Internal Dimensions (mm) | Capacity (m³/min) | Impeller Motor Power (kW) | Weight per Cell (kg) |
Air Intake Volume (m³/min) |
| SF-1.2 | 1.2 | 1100×1100×1100 | 0.6-1.2 | 5.5 | 1450 | 1-1.1 |
| SF-2.8 | 2.8 | 1700×1600×1150 | 1.4-3.0 | 11 | 2210 | 0.9-1.1 |
| SF-4 | 4 | 1900×2000×1200 | 2-4 | 15 | 2720 | 0.9-1.1 |
| SF-8 | 8 | 2200×2900×1400 | 4-8 | 30 | 4280 | 0.9-1.1 |
| SF-10 | 10 | 2200×2900×1700 | 5-10 | 30 | 4800 | 0.9-1.1 |
| SF-16 | 16 | 2900×3800×1700 | 8-16 | 37 | 8430 | 0.9-1.1 |
| SF-20 | 20 | 2900×3800×2000 | 10-20 | 45 | 8810 | 0.9-1.1 |
| SF-24 | 24 | 3100×4200×2000 | 12-24 | 45 | 8910 | 0.9-1.1 |
| SF-30 | 30 | 3400×4500×2100 | 15-30 | 55 | 14130 | 0.9-1.1 |
| SF-40 | 40 | 3950×4750×2250 | 18-40 | 75 | 17370 | 0.9-1.1 |
| SF-50 | 50 | 4400×4900×2400 | 23-46 | 90 | 23410 | 0.9-1.1 |
