1. Crushing & Screening

The raw ore enters the jaw crusher through the feeder for primary crushing and then enters the cone crusher for medium crushing. After the vibrating screen screening, the materials under the screen enter the grinding process while the screened materials enter the fine-crushing process. And select the cone crusher for the fine-crushing operation.

2. Grinding & Grading

It often uses a stage grinding process when processing nickel ore. The crushed products enter the ball mill for a stage of grinding and then enter the spiral classifier for pre-classification. If the ore particle size of nickel ore is too coarse (greater than 0.1mm) or too fine (less than 0.006mm), it is unfavorable for the subsequent flotation. Therefore, after the pre-classification, set up a hydrocyclone to control the pulp classification. The overflow part of the hydrocyclone is qualified ore particles, and the bottom flow is unqualified ore particles that need to enter the ball mill for regrinding. To improve the grinding efficiency of the ball mill, we install a ball mill after the hydrocyclone for regrinding.

3. Flotation

In the flotation of nickel ore, to improve the utilization efficiency of materials and the grade of concentrate, it can generally be divided into flotation operations of high-grade concentrates and flotation operations of ordinary concentrates.

High-grade nickel concentrate flotation

When sorting high-grade nickel ore concentrates, the flotation process of “one rough and two fine” is generally adopted.

Process: The slurry pump pumps the qualified ore pulp(after classifying) into the flotation machine for a roughing stage(rough). The obtained roughing concentrate enters the beneficiation process, undergoes two concentration(fine) flotations, and finally obtains high-grade nickel ore concentrate.

Ordinary Concentrate Flotation

After a rough selection, the tailings also contain a certain amount of nickel ore concentrate. In order to improve the recovery efficiency of concentrate ore and the utilization efficiency of materials, it is necessary to sort tailings again.

Process: Classify the tailings of the primary roughing of nickel ore first. The underflow materials enter the ball mill for secondary grinding, and the overflow materials enter the flotation machine for roughing of tailings. For the flotation of ordinary concentrate, the technological process of “one rough, three fine, and two sweeps” is generally adopted. The tailings of a roughing stage and the ore pulp after grinding will enter the hydrocyclone to classify. The tailings roughing concentrate enters into three beneficiation operations. The remainder goes to two sweeping operations for the tailings. After three times of beneficiation, it can obtain nickel ore concentrate.

4. Dehydration & Drying

The water content of the material after flotation is relatively large. In order to speed up the drying speed of the product, usually use a concentrator to dehydrate, and a dryer to dry the material to obtain a finished product.
